APPLICATION OF INDUCED POLARIZATION (IP) METHOD FOR IDENTIFYING METALLIC MINERAL DISTRIBUTION IN THE LEON AREA

Elleona Septi Nugraheni; Y Yatini; Agus Santoso

doi:10.30556/imj.Vol26.No2.2023.1344

Authors

Elleona Septi Nugraheni Department of Geophysics, Universitas Pembangunan Nasional Veteran Yogyakarta
Y Yatini Universitas Pembangunan Nasional Veteran Yogyakarta
Agus Santoso Department of Geophysics, Universitas Pembangunan Nasional Veteran Yogyakarta

DOI:

https://doi.org/10.30556/imj.Vol26.No2.2023.1344

Keywords:

chargeability, induced polarization, metallic minerals, resistivity

Abstract

The research was conducted in the Leon area to determine the presence and quantity of metallic mineral resources. The stratigraphy of the study area is composed of alluvium and coastal deposits, Molasa Sarasin Formation, Tinombo Formation, and Intrusion. Exploration was carried out in the Leon area using Induced Polarization Method with a dipole-dipole configuration with an area of 950 m². The length of the track is 580 meters with a North-South orientation. The number of tracks in this study was 15, with spacing electrodes as far as 20 meters and n = 1-10. The analysis showed that the distribution of resistivity values in the study area was from (13.6 to 1337) Ωm, while the chargeability values had a range of values (1.7 to 50.6) ms. The low resistivity values below 50 Ωm are interpreted as claystone to sandstone and the medium resistivity values between 50 Ωm - 500 Ωm are interpreted as compact sandstone to breccia. The resistivity values above 500 Ωm are interpreted as igneous rock. The presence of metallic minerals in the study area is characterized by changeability values above 22 ms in claystone, sandstone, breccia, and igneous rock. Calculating hypothetical resources was conducted the Block model method at Oasis Montaj that obtained 11.8 million tons of resources.

References

Alpiandi, R. (2021) Identifikasi sebaran bijih besi di bawah permukaan menggunakan metode electrical resistivity dan induced polarization di Nangabulik, Kalimantan Tengah. Universitas Islam Negeri Syarif Hidayatullah.

Antonelli, F., Stevanato, R., Fries, M., Abreu, G., Ferreira, F. and Serrano, V. (2019) ‘Resistivity and induced polarization applied to epithermal gold deposit in the Torre Target, at Castro Basin-PR’, in Proceedings of the 16th International Congress of the Brazilian Geophysical Society&Expogef. Brazilian Geophysical Society, pp. 1–5. Available at: https://doi.org/10.22564/16cisbgf2019.135.

Bodjawati, M.S., Heditama, D.M. and Muttaqin, Y.A. (2020) ‘Identifikasi Zona Mineralisasi Bijih Besi Menggunakan Metode Polarisasi Terinduksi di Daerah Ulusuliti dan Tanjung Lima Kapas, Solok Selatan, Sumatra Barat’, Buletin Sumber Daya Geologi, 15(3), pp. 140–154. Available at: https://doi.org/10.47599/bsdg.v15i3.307.

Cahyono, J.W. (2020) Eksplorasi mineral logam dengan metode geolistrik induksi polarisasi (IP) konfigurasi dipole-dipole pada lapangan Bisori, Halmahera Selatan, Maluku Utara. Universitas Pembangunan Nasional ‘Veteran’ Yogyakarta.

Dakir, I., Benamara, A., Aassoumi, H., Ouallali, A. and Ait Bahammou, Y. (2019) ‘Application of induced polarization and resistivity to the determination of the location of metalliferous veins in the Taroucht and Tabesbaste Areas (Eastern Anti-Atlas, Morocco)’, International Journal of Geophysics, 2019, pp. 1–11. Available at: https://doi.org/10.1155/2019/5849019.

Fajariyah, E.N. and Supriyadi (2014) ‘Aplikasi metode time domain induced polarization (TDIP) untuk pendugaan zona mineralisasi emas di Desa Jendi Kecamatan Selogiri Kabupaten Wonogiri’, Unnes Physics Journal, 3(1), pp. 22–26.

Ferial, D., Natalisanto, A.I. and Lazar, P.A.D. (2019) ‘Identifikasi sebaran mineral bijih besi dengan menggunakan metode resistivitas dan induced polarization (IP) di Kecamatan Muara Uya, Kabupaten Tabalong, Provinsi Kalimantan Selatan’, Jurnal Geosains Kutai Basin, 2(2), pp. 1–9.

Hasria, Idrus, A. and Warmada, I.W. (2019) ‘Alteration alteration, mineralization and geochemistry of metamorphic rocks hosted hydrothermal gold deposit at Rumbia Mountains, Bombana Regency, Southeast Sulawesi, Indonesia’, Journal of Geoscience, Engineering, Environment, and Technology, 4(2), pp. 83–92. Available at: https://doi.org/10.25299/jgeet.2019.4.2.2346.

Kim, B., Nam, M.J., Jang, Hannuree, Jang, Hangilro and Kim, H.J. (2017) ‘The principles and practice of induced polarization method’, Geophysics and Geophysical Exploration, 20(2), pp. 100–113. Available at: https://doi.org/https://doi.org/10.7582/GGE.2017.20.2.100.

Lowrie, W. (2007) Fundamentals of Geophysics. 2nd edn. Cambridge University Press. Available at: https://doi.org/10.1017/CBO9780511807107.

Mao, D., Revil, A. and Hinton, J. (2016) ‘Induced polarization response of porous media with metallic particles — Part 4: Detection of metallic and nonmetallic targets in time-domain induced polarization tomography’, GEOPHYSICS, 81(4), pp. D359–D375. Available at: https://doi.org/10.1190/geo2015-0480.1.

Maskuri, F. (2010) ‘Identifikasi bahan galian dalam metode eksplorasi awal’, Jurnal Ilmiah MTG, 2(5), pp. 1–10.

Rahayu, H., Ribowo, A. and Karlina, F.H. (2019) ‘Pendugaan mineral mangan menggunakan metode induced polarization konfigurasi Wenner di Jurang Gandol, Tegalombo, Pacitan’, in A. Yuniati, N. Handayani, Widayanti, F.A. Rakhmadi, C. Yanuarif, N. Untoro, R. Resmiyanto, and Winarti (eds) Prosiding Seminar Nasional Fisika Festival 2019. Yogyakarta: Universitas Islam Negeri Sunan Kalijaga Yogyakarta, pp. 64–70.

Ratman, N. (1976) Peta geologi lembar Tolitoli, Sulawesi Utara. Bandung: Direktorat Geologi, Departemen Pertambangan, Republik Indonesia.

Rauf, A. (2012) ‘Mineralisasi bijih besi di Kabupaten Donggala Provinsi Sulawesi Tengah’, in Prosiding Simposium dan Seminar Geomekanika Ke-1 Tahun 2012. Yogyakarta: Universitas Pembangunan Nasional ‘Veteran’ Yogyakarta, pp. 4-54-4–60.

Revil, A., Florsch, N. and Mao, D. (2015) ‘Induced polarization response of porous media with metallic particles — Part 1: A theory for disseminated semiconductors’, GEOPHYSICS, 80(5), pp. D525–D538. Available at: https://doi.org/10.1190/geo2014-0577.1.

Reynolds, J.M. (2011) An Introduction to Applied and Environmental Geophysics. 2nd edn. Chichester: John Wiley & Sons, Ltd.

Safitri, B.R.A. (2019) ‘Analisis kandungan mineral logam mangan (Mn) di kawasan pertambangan Desa Bangkang’, Jurnal Ilmiah IKIP Mataram, 6(1), pp. 9–15.

Santoso, A. (2016) Penentuan pusat erupsi gunung api purba berdasarkan metode gravitasi, geomagnetik dan geolistrik di daerah Gunungkidul dan sekitarnya Daerah Istimewa Yogyakarta. Universitas Gadjah Mada.

Santoso, B., Wijatmoko, B. and Supriyana, E. (2017) ‘Kajian nikel laterit dengan metode electrical resistivity tomography di daerah Batu Putih, Kolaka Utara Sulawesi Tenggara’, Jurnal Material dan Energi Indonesia, 7(01), pp. 24–30. Available at: https://doi.org/10.24198/jmei.v7i01.11043.

Seizarsyah, T., Setiahadiwibowo, A.P., Maskuri, F. and Sutarto, S. (2022) ‘Identification of alteration-mineralization in skarn deposit system based on time-domain induced polarization method approach in Kasihan area, Pacitan, East Java’, JURNAL GEOCELEBES, 6(1), pp. 56–63. Available at: https://doi.org/10.20956/geocelebes.v6i1.17558.

Sidiq, M., Yatini, Y. and Fajrin, A. (2021) ‘Application of magnetic and induced polarization method for delineating gold-bearing vein zones at Cibaliung, Pandeglang Regency, Banten’, Indonesian Mining Journal, 24(1), pp. 1–14. Available at: https://doi.org/10.30556/imj.Vol24.No1.2021.1133.

Sompotan, A.F. (2012) Struktur geologi Sulawesi. Bandung: Institut Teknologi Bandung.

Sony (2019) Indonesia salah satu penghasil tambang terbesar di dunia, feb.ugm.ac.id. Available at: https://feb.ugm.ac.id/id/berita/2877-indonesia-salah-satu-penghasil-tambang-terbesar-di-dunia (Accessed: 12 June 2022).

Srigutomo, W., Trimadona and Pratomo, P.M. (2016) ‘2D resistivity and induced polarization measurement for manganese ore exploration’, Journal of Physics: Conference Series, 739, p. 012138. Available at: https://doi.org/10.1088/1742-6596/739/1/012138.

Syafrizal (2013) Materi perkuliahan pemodelan dan evaluasi cadangan. Bandung.

Umroh, Z. (2018) Analisis data geolistrik metode IP (induced polarization) untuk , mengetahui sebaran lumpur di bawah permukaan: Studi kasus Desa Jari, Kecamatan Gondang, Kabupaten Bojonegoro. Universitas Islam Negri Maulana Malik Ibrahim.

Waskito, A.W. (2020) Identifikasi persebaran batuan pembawa mineral logam berdasarkan data induksi polarisasi konfigurasi dipole-dipole lapangan X, Kabupaten Donggala, Sulawesi Tengah. Universita Pembangunan Nasional ‘Veteran’ Yogyakarta.

Yatini (2018) ‘Influence of clay on time domain induced polarization’, Indonesian Journal of Science and Technology, 3(1), pp. 1–10. Available at: https://doi.org/10.17509/ijost.v3i1.10794.

Yatini, Y., Santoso, D., Laesanpura, A. and Sulistijo, B. (2022) ‘Effectiveness of laboratory physical modeling in acquiring the response of time domain induced polarization (TDIP)’, Jurnal Penelitian Fisika dan Aplikasinya (JPFA), 12(1), pp. 34–46. Available at: https://doi.org/10.26740/jpfa.v12n1.p34-46.

Yuniarto, A.H.P. (2020) ‘Aplikasi time domain induced polarization dalam eksplorasi emas di Blok “Cpy” Gunung Pongkor Kabupaten Bogor’, Jurnal Geosaintek, 6(3), pp. 117–126. Available at: https://doi.org/10.12962/j25023659.v6i3.6867.
