PROCESSING ZIRCONIA THROUGH ZIRCON SAND SMELTING WITH NaOH AS A FLUX

Authors

  • Yuhelda Yuhelda R&D Centre for Mineral and Coal Technology
  • Dessy Amalia R&D Centre for Mineral and Coal Technology
  • Enggan P. Nugraha R&D Centre for Mineral and Coal Technology

DOI:

https://doi.org/10.30556/imj.Vol19.No1.2016.364

Keywords:

zirconia, zircon sand, smelting, upgrading process and concentrate

Abstract

Zirconia had been made through smelting the zircon sand along with NaOH as a flux. The zircon sand as the smelter feed was taken from CV. Kurnia Alam Sejati mine at Palangkaraya, Middle Kalimantan. Major content of the zircon sand was 28.04% ZrO2 and SiO2 51.22% with several minor oxides such as 0.54% HfO2, 2.53% Fe2O3, 10.53% TiO2, 3.27% Al2O3 and less than 1% of alkali, alkaline earth and rare earth elements. In order to economizing the process, zircon sand upgrading was conducted prior to zirconia production. The upgrading process was conducted using several comprehensive equipments, consist of shaking table, magnetic separator and high tension separator (HTS).The upgraded sand contained 65.35% of ZrO2+HfO2 with 73.25% recovery, which was then used for smelting process at 650C for 2 hours using NaOH as a flux. The product was then leached with water and sulphuric acid then crystallized to get precipitated zirconium hydroxide. The precipitated product was calcined at 900C for 1 hour to get the zirconia and analyzed for its content. The zirconia content was 97.27% of ZrO2+HfO2 with 65.13% recovery.

References

Anonim, 2006. Aplications and preparations of zirconia and stabilized zirconia powders. http://www.standfordmaterials.com accessed on 31 May 2006 at 15.40

http://www.zirox.co.in/advanced_materials_division.htm, browsed on 15 September 2009 at 13.44.

Anonim, 2010. Zinc and Zirconia. Booklet of learning Material warkshop, The Royal Society of Chemistry, London

Anonim, 2008. Demonstration Pilot Plant Commissioning Brings World Class Dubbo Zirconia Project closer. ASX Announcement, 6 pages. http://www.alkane.com.au/pdf/asx/archive/20080408.pdf.

Bobbin, 2008. Komputasi numerik untuk analisis karakteristik keramik psz dengan aditif Cao, mgo berbasis matlab. Tesis, Pasca Sarjana Universitas Sumatra Utara, Medan.

Kwela, Z., 2006. Alkali-fusion processes for the recovery of zirconia and zirconium chemical from zircon sand. Dissertation. Faculty of Engineering Built Environment and Information Technology, University of Pretoria,147 p.

Harben, P.W., 1995. The Indutrial Minerals Handy Book, 2nd edition, Industrial Minerals Devision, Metal Bulletin PLC, London, United Kingdom.

Rehim, A. M., 2005. A new technique for extracting zirconium from egiptian zircon concentrate. International Journal of Mineral Processing, 76, p. 234-243.

Saleh, N. and Pramusanto, 2007. Heavy Mineral Sands Separation of Waringin, Central, Kalimantan. Prosiding Kolokium Pertambangan, p. 147-156.

Yuhelda, Pramusanto, Saleh, N.; Wahyudi, A., Rodliyah, I., Setyatmoko, E., Somantri, 2008. Pembuatan zirconia dari pasir zirkon. Laporan Penelitian. Puslitbang Teknologi Mineral dan Batubara, Bandung.

Yuhelda, Pramusanto, Saleh N., Setyatmoko E., Somantri, 2009. Pembuatan zirconia semi stabil. Laporan Penelitian. Puslibang Teknologi Mineral dan Batubara, Bandung.

Yuhelda, Pramusanto, Saleh N., Amalia D., Setyatmoko E. Somantri, 2010. Pembuatan zirconia stabil. Laporan Penelitian. Puslitbang Teknologi Mineral dan Batubara, Bandung.

Yuhelda, Pramusanto, Saleh N and Amalia D, 2012. Optimalisasin Pelarutan Natrium zirkonat secara kontiniu. Laporan Penelitian. Puslibang Teknologi Mineral dan Batubara, Bandung.
