EVALUATION OF SELECTED HIGH RANK COAL IN KUTAI BASIN, EAST KALIMANTAN RELATING TO ITS COKING PROPERTIES
DOI:
https://doi.org/10.30556/imj.Vol18.No1.2015.301Keywords:
coking coal, maceral, vitrinite reflectance, crucible swelling numberAbstract
Abundant coal seams of Miocene age with thickness of up to 4.7 metres occur in Kutai Basin, East Kaliman- tan. Selected coals are analyzed in order to evaluate its coking properties. The coals have bituminous in rank with calorific value of 5,582-8,357 kg/kcal (adb) and vitrinite reflectance of 0.57-0.97%. These selected high rank coals are normally concentrated in high gradient temperature zone or proximity to intrusive body. Vitrinite reflectances of these coals are lower than those of Australian coking coals (1.04-1.06%), but higher than of Indonesian normal coalification coals. Vitrinite is the dominant maceral in coals from Kutai Basin (73-96%), while inertinite and liptinite are only present in small amount, i.e. trace-10.2% and trace-8.2%, respectively. In contrast, vitrinite is lower and inertinite is higher in Australian coking coals, i.e. 64.8- 79.0% and 18.4-31.6%, respectively. Generally, crucible swelling number of Kutai Basin coals is lower than of Australian coking coals. Based on its vitrinite reflectance and calorific values, some of selected high rank coals from Kutai Basin have developed semi coking properties. The enhancement of rank is probably due to the effect of igneous intrusions or high gradient temperature. However, vitrinite content of the coals is higher than of coking coal range. Crucible swelling number of the coal is also too low, except for sample EK 1 and EK 2 which have CSN too much of 6 and 4, respectively. Therefore, the coals are not categorized as prime coking coal, but they can be blended with bituminous inertinite rich coals to make metallurgical coke for blast furnace.
References
American Society for Testing Materials, 2009. Manual book of ASTM standard. Section 5 volume 05.06, America, ASTM International, 2009.
Australian Standard, A., 1998. Coal petrography. Part 2: Maceral analysis. AS 2856.2-1998. Council of Standards Australia, Strathfield, NSW, Australia, 32 pp.
Australian Standard, 2000. Coal petrography. Part 3: Methods for microscopical determination of the reflectance of coal macerals. AS 2856.3-2000. Council of Standards Australia, Strathfield, NSW, Australia, 17 pp.
Badan Geologi, 2013. Sumber daya dan cadangan batubara Indonesia. Badan Geologi, Kementerian Energi dan Sumber Daya Mineral.
Daulay, B., 1994. Teriary coal belt in eastern Kalim- antan, Indonesia: the influence of coal quality on coal utilization. PhD thesis, the University of Wol- longong. Wollongong, Australia, 326 p (unpubl.).
Daulay, B., 1998. Potensi batubara kokas (coking coal) di dalam cekungan Tersier Indonesia. Technical paper, Mineral Technology Reasearch and Devel- opment Centre, Bandung, p. 6-10.
Daulay, B. and Cook, A.C., 1988. The petrology of some Indonesian coals. Journal of Southeast Asian Earth Sciences 2 (2), p. 45–64.
Daulay, B., Umar, D.F., Santoso, B. and Suganal, 2010. Evaluation of Kalimantan coal quality in order to select the appropriate and effective utilization tech- nologies. Indonesian Mining J.,13, pp. 83-93.
Diez, M.A., Alvarez, R. and Barriocanal, C, 2002. Coal for metallurgical coke production: predictions of coke quality and future requirements for coke making. International Journal of Coal Geology, 50, p. 389– 412.
Directorate General of Mineral and Coal, 2014. Country reports updates of Indonesia. Paper presented at 12th AFOC Council Meeting Thailand, 21-22 May 2014. Directorate General of Mineral and Coal, Ministry of Energy and Mineral Resources.
ISO, 2009a. Methods for the petrographic analysis of coals. Part 3: Method of determining maceral group composition. ISO 7404-3. International Organiza- tion of Standardization, Geneva, Switzerland, 7 p.
ISO, 2009b. Methods for the petrographic analysis of coals. Part 5: Method of determining microscopi- cally the reflectance of vitrinite. ISO 7404-5. Inter- national Organization of Standardization, Geneva, Switzerland, 14 p.
Katili, J.A., 1989. Evolution of the Southeast Asian arc complex. Geol. Indo., Jakarta, 12, p. 113-143.
Koesoemadinata, R.P., 1978. Sedimentary framework of Tertiary coal basins of Indonesian. In Third Regional Conference on Geology and Mineral Resources of South-east Asia, Bangkok, Thailand, p. 621-639.
Moss, S.J. and Chambers, J.L.C., 1999. Tertiary facies architecture in the Kutai Basin, Kalimantan, Indo- nesia. J. Asian Earth Sci. 17, 157–181.
Moore, T.A. and Friederich, M.C., 2010. A probabilis- tic approach to estimation of coalbed methane resources for Kalimantan, Indonesia. In: Basuki, N.I., Prihatmoko, S. (Eds.), Kalimantan coal and mineral resources. MGEI-IAGI Seminar, 29–30 March 2010, Balikpapan, Indonesia, p. 61–71.
Moore, T.A. and Nas, C., 2013. The enigma of the Pinang Dome (East Kalimantan): a review of its origin, significance and influence on coal rank and coalbed methane properties. 37th Annual Convention & Exhibition, Indonesian Petroleum Association. Indonesian Petroleum Association, Paper IPA13-G-119, Jakarta, Indonesia.
Moore, T.A, Bowe, M. and Nas, C., 2014. High heat flow effects on a coalbed methane reservoir, East Kalimantan (Borneo), Indonesia. International Journal of Coal Geology, 131, p. 7–31.
Pareek H.S., 1986. The role of coal petrographic characteristics in evaluating the non-coking nature of the coals of Ramagundam and Kothagudem coalfields, Godavari Valley Basin, Andhra Pradesh, India. International Journal of Coal Geology, 6 , p. 181—198.
Prakash, K.S., Singh, M.P., Singh, A.K. and Arora, M., 2010. Petrographic characteristics of coal from the Lati Formation, Tarakan basin, East Kalimantan, Indonesia. International Journal of Coal Geology, 81, p. 109–116.
Rose, R. and Hartono, P., 1978. Geologic evolution of the Tertiary Kutai-Melawi Basin, Kalimantan, Indo- nesia. Proc. Indo. Petrol. Assoc, 7th Ann. Conv., Jakarta, p. 225-251.
Santoso, B. and Daulay, B., 2009. Geologic and petrographic aspects for coal exploration in Sangatta-East Kalimantan. Indonesia Mining J., 12, p. 10–22.
Santoso, B., 2015. Petrologi batubara Sumatera dan Kalimantan: Jenis, peringkat dan aplikasi. LIPI Press, Jakarta, 132 p.
Satyana, A.H., Nugroho, D. and Surantoko, I., 1999. Tectonic controls on the hydrocarbon habitats of the Barito, Kutai, and Tarakan Basins, Eastern Ka- limantan, Indonesia: major dissimilarities in adjoin- ing basins. J. Asian Earth Sci., 17, p. 99–122.
Sarana, S. and Kar, R, 2011. Effect of igneous intrusive on coal microconstituents: Study from an Indian Gondwana coalfield. International Journal of Coal Geology, 85, p. 161-167.
Sikumbang, N., 1986. Geology and tectonic of pre- Tertiary rocks in the Meratus Mountains, Southeast Kalimantan, Indonesia. PhD Thesis, Royal Hollo- wayand Bedford New College, The University of London, London, 400 p., (Unpubl.).
Singh, A.K., Singh, M.P., Sharma, M. and Srivastava, S.K., 2007. Microstructures and microtextures of natural cokes: a case study of heat-altered coking coals from the Jharia Coalfield, India. International Journal of Coal Geology, 71, p. 153–175.
Singh, A.K., Sharma, M. and Singh, M.P., 2008. Gen- esis of natural cokes: some Indian examples. Inter- national Journal of Coal Geology, 75, p. 40–48.
Shui, H., Li, H., Chang, H., Wang, Z., Gao, Z., Lei, Z. and Ren, S., 2011. Modification of sub-bituminous coal by steam treatment: caking and coking properties. Fuel Processing Technology 92, p. 2299–2304.
Thomas, L., 2007. Coal Geology. Wiley, England, 384 p.
Van Bemmelen, R.W., 1949. The geology of Indonesia. General geology of Indonesia and adjacent archi- pelagos. The Hague, Netherlands, IA, 732 p.
Widodo, S., Oschmann, W., Bechtel, A., Sachsenhofer, R.F., Anggayana, K. and Puettmann, W., 2010. Distribution of sulfur and pyrite in coal seams from Kutai Basin (East Kalimantan, Indonesia): Implications for paleoenvironmental conditions. International Journal of Coal Geology 81 (2010), p. 151–162
